Understanding the Benefits of Hospital Frame Tents: A Community Perspective

Introduction to Hospital Frame Tents

Hospital frame tents are versatile structures designed to provide shelter in various situations, including emergency medical services and community health initiatives. Made from high-quality polyester cotton canvas, these tents ensure durability and resilience in challenging environments.

Specifications You Can Trust

Crafted with a robust fabric that boasts water and rot-proof characteristics, the hospital frame tent is engineered for exceptional performance. Weighing approximately 440 g/m2, the fabric ensures that it withstands wear and tear while providing ultimate UV resistance. Such specifications make the tent a reliable choice for healthcare and community settings.

Community Impacts and Usage

Utilizing a community tent like the hospital frame tent can significantly enhance public health response efforts. These structures offer a flexible solution for triaging patients during emergencies and can also serve as vaccination centers or community health fairs. Their easy setup and reliable protection empower communities to deliver vital services efficiently and safely.

In conclusion, the hospital frame tent stands as a cornerstone of community health resilience. Its sturdy construction, along with water and UV resistant features, ensures that it meets diverse community needs while fostering trust during critical times.

FabricMade of polyester cotton canvas water, rot proof + UV resistance 440 g/m2 ( -/+ 5%)
Ground Sheet & Mud flap Optional : Made of 540 g/m2 ( +/- 5%) PVC Both side coated Fabric
SeparationOptional : Inner Separation with the same tent Fabric 440 g/m2 PC canvas
Door & Windows 2 Doors + 4 Windows
Standard functioning and practical tent for rapid deployment in Emergency field hospital, Health center, Epidemic Treatment Center, Storage, Logistical center, etc.

Multiple attachments of these tents can be done seamlessly to form a much larger working area as per need.

This type of tent is especially designed for its resistance to wind, rain, UV and microorganisms. The polyester/cotton canvas combines strength, durability, waterproof, and breathing capacities.

The tent can be delivered without options or with the following:

A bathtub ground sheet to cover the complete surface of the tent.
It has a minimum shelf life of 5 years under normal warehousing conditions (in a dry, clean and ventilated warehouse – not in containers or tented warehouses – and stored on pallet racks or pallets elevated off the ground, not piled). The tent is vulnerable to rain and moisture when packed. Expected life span is 1 year in all environments.

Setting up requires 6 persons, and take 30 min (instructions included). Avoid setting it up under trees as this will lead to canvas rotting. Use all ground fixings to ensure the maximum wind resistance. Does not include ground sheet, can be made with plastic tarpaulins, or ordered separately.

Dimensions

1. Width x Length – 5.1M x 6.30 M
Useable Area – 32.10 M2 (Approx.)
Centre Height – 3 M
Wall height – 1.8 M
People – 18- 20 Persons capacity
Approx. Weight -120kg Approx. CBM – .385

2. Width x Length – 5.1 Mts x 8.40 Mts
Useable Area 42.85 M2 (Approx.)
Centre Height 3.00 M
Wall height 1.8 M
People 20-40 person capacity
Approx. Weight – 130kg Approx. CBM – .435

3. Width x Length – 5.1 Mts x 14.70 Mts
Useable Area 75 M2 (Approx.)
Centre Height 3.00 M
Wall height 1.8 M
People 40-50 person capacity
Approx. Weight – 465 kg Approx. CBM – 1.15
